3-26
Controls - Cab
X6 - P/N 6525032M1
Revolving beacon switch
(if equipped) - (Fig. 3-47)
Pos. A: the revolving beacon lights up (of 2 beacons are
installed, both will be turned on at the same time)
Pos. B: revolving beacon OFF
Fig. 3-47
Rear view mirror heating switch (de-
froster) - (Fig. 3-49)
(if equipped).
Pos. A: supply to the rear view mirror resistances (ON)
(central blue indicator light on)
Pos. B: no supply to the rear view mirror resistances (OFF)
IMPORTANT: Turn the mirror heater off after 10 minutes
to avoid damage.
Fig. 3-49
Ad d iti o na l l o w b eam s s w itc h
(if equipped) - (Fig. 3-48)
Pos. A: the 2 dipped beams on the handgrips are on
Pos. B: the dipped beams on the bonnet are on
NOTE: The low beams on the bonnet, if there is no switch
for auxiliary beams, are controlled by the switch (2 Fig.
3-35) in position C.
Fig. 3-48
A
B
A
B
A
B
Pos. A
Pos. B
