3-28
Controls - Cab
X6 - P/N 6525032M1
Tractor Warning Lamp Usage
- The flashing amber warning lamps must be used ac-
cording to road traffic laws.
The amber warning lamps are used to indicate a hazard
to other road users. Press button (1) to activate. By this
switch all four turn indicators will flash on and off.
IMPORTANT:
When operating the tractor, towing an
implement or trailer, the complete rear area warning
system (amber warning lamps, when applicable, and red
tail lamps) must be easily seen by any vehicle operator
coming near the tractor.
Implement warning lamps
(if equipped).
It is recommended that implement warning lamps are
used:
- If the flashing warning lamps and red tail lamps on the
tractor cannot be seen because they are obstructed by
the implement.
- If the towed implement is 1219 mm or more behind the
hitch point of the tractor.
- If the towed implement is 1219 mm or more to the left
or right of the centre of the tractor.
- If the towed implement is 3000 mm or more wide.
Install the warning lamps to indicate the side of the imple-
ment nearest the centre of the road.
Rotating Beacon
- The rotating amber beacon must be used according to
local road traffic laws.
The revolving amber beacon is operated by pressing the
switch (2) with the flashing beacon symbol. If the tractor
is provided with 2 revolving beacons, the switch (2) lights
up both.
Slow Moving Vehicle (SMV) Symbol
- For correct use of the SMV symbol, respect local road
traffic laws.
If a Slow Moving Vehicle symbol is equipped, it must be
installed on the rear part of the tractor.
To install the SMV symbol on an implement or trailer a
special bracket must be obtained from your dealer.
1
WARNING: Collision of high speed road traffic
and tractors or implements can cause personal
injury or death. On roads, use amber warn-
ing lamps according to local laws. Keep SMV
emblem visible. Pull over to let faster traffic
pass. Slow down and signal before turning off.
