3. Configure the test endpoint parameters as desired. See the table below for a
description of these parameters.
4. Click Submit to apply your settings.
Test Call Table Parameters
Parameter Description
General Tab
Endpoint URI
[Test_Call_Endpoin
tURI]
Defines the endpoint's URI. This can be defined as a user or user@host.
The device identifies this endpoint only by the URI's user part. The URI's
host part is used in the SIP From header in REGISTER requests.
is not configured.
Route By
[Test_Call_DestTyp
e]
Defines the type of routing method. This applies to incoming and outgoing
calls.
[0] GW Tel2IP = (Default) Calls are matched by (or routed to) an SRD
and Application type (defined in the SRD and Application Type
parameters below).
[1] IP Group = Calls are matched by (or routed to) an IP Group ID.
[2] Dest Address = Calls are matched by (or routed to) an SRD and
application type.
Notes:
For REGISTER messages, the option [0] cannot be used as the routing
method.
For REGISTER messages, if option [1] is used, only Server-type IP
Groups can be used.
IP Group ID
[Test_Call_IPGroup
ID]
Defines the IP Group ID to which the test call is sent or from which it is
received.
Notes:
This parameter is applicable only if option [1] is configured for the 'Route
By' parameter.
This IP Group is used for incoming and outgoing calls.
Destination Address
[Test_Call_DestAd
dress]
Defines the destination host. This can be defined as an IP address[:port] or
DNS name[:port].
Note: This parameter is applicable only if the 'Route By' parameter is set to
[2] (Dest Address).
Destination
Transport Type
[Test_Call_DestTra
nsportType]
Defines the transport type for outgoing calls.
[-1] Not configured (default)
[0] UDP
[1] TCP
[2] TLS
Note: This parameter is applicable only if the 'Route By' parameter is set to
[2] (Dest Address).
Application Type
[Test_Call_Applicat
ionType]
Defines the application type for the endpoint.
[0] GW & IP2IP (default)
