DP MODE
DP communication is monitored, the DP watchdog in the master is acti
-
vated. Thus, the failure function is available
WAIT PRM
The Profibus DP interface is waiting for correct parameter data
WAIT CFG
The Profibus DP interface is waiting for correct configuration data
DATA EX
The Profibus DP interface is currently exchanging data with the master
DP FAULT
The internal status machine has detected a fault. Remedy: Switch AUMATIC
off and on
GC CLEAR
The Profibus DP interface has received a Global Control CLEAR telegram
and is waiting for the Global Control Operate telegram. In this state, the DP
communication is fully operational, however, the actuator cannot be oper-
ated from REMOTE. It is triggered if the failure function is activated
DATA WITH LENGTH 0
The Profibus DP interface receives data with length 0 (FailSafe telegrams).
In this state, the DP communication is fully operational, however, the actua-
tor cannot be operated from REMOTE. It is triggered if the failure function is
activated
Positioner (DF)
È
Description of the display:
POSITIONER
Determined values of the adaptive positioner.
Line 2: inner deadband CLOSED, line 3: outer deadband, line 4: inner dead
band OPEN.
DP2 hardware version (DG)
È
Description of the display:
DP2 HRDWR.VER.
Hardware version of the Profibus DP interface
103
Actuator controls
Manual AUMATIC AC 01.1/ACExC 01.1 Profibus DP


DP2 HRDWR.VER. DG


POSITIONER DF
