Austro Engine AE330 - Page 181

Maintenance Manual
E4.08.04
Issue date: 14-Apr-2015
Page: 71-45
Revision no: 25
Fig. 71 - 64
One edge clip has to be mounted as shown at Fig. 71 – 64. It shall be used to fix the branch of
CRS2. The pigtail of CRS2 has to be connected to the screw (11 Nm) of CRS2.
Fig. 71 - 65
The governor pigtail is included to the bayonet connector GOV. No additional screwing of pigtail is
therefore needed.
Branch CRS2
07
CRS2
Pigtail CRS2
07
Governor
