Fig. 71 - 66
The installer of the engine harness is allowed to use the same cable tie type for additional fixation, if
the described fixation points are not sufficient. It has to be ensured by installer that the additional
cable ties are not directly mounted to driven or hot parts of the engine.
If it is required the installer is allowed to use cable ties 05 and Edge Clips (06; 07; 08) to fix the
engine harness additional. In such a case of an additional fixation with the described materials it has
to be ensured that the branches with the used materials are not attached to hot areas.
