R5906848 /04 DP2K SLP Series 307
Situation Solution
Malfunction zoom motor of the
lens.
Use the local keypad to zoom the image on the screen. If unsuccessful,
replace the motorized lens or replace the motor assembly of the lens. See
service procedure “Replacement of the motor assembly for 0.69" DC2K
lenses (Type 'M')”, page 190.
Malfunction Signal Backplane
(bad connection).
Replace the Signal Backplane. See service procedure “Card Cage”, page
209.
Image 25-33
Image 25-34
Image 25-35
Code 5231: “Lens focus position - Requested target not reached”
Situation Solution
Manual lens installed. Replace the manual lens with a motorized lens.
Lens not correctly installed. Check of the lens is correctly installed. See service manual chapter “Lens
installation”, page 176.
The activated lens file does
not correspond with the lens
mounted on the projector.
Activate a lens file which does correspond with the mounted lens or mount
an other lens which correspond with the lens file you want to activate.
Corrupt lens file. Delete the lens file and program correct lens type into communicator under
Advanced/lens parameters and recreate a new lens file.
Tip: perform a “Lens Homing” before creating a new lens file. Otherwise, if
the lens is removed the existing lens file becomes useless. Setup all new
lens files away from the maximum limitation of the lens zoom. It is possible
