Barco DP2K SLP Series Service Manual

R5906848 /04 DP2K SLP Series 325
Situation Solution
1.80V Supply out of range Replace the ICP board. See service manual chapter “Replacement of the
ICP board”, page 214.
2.50V Supply out of range Replace the ICP board. See service manual chapter “Replacement of the
ICP board”, page 214.
3.30V Supply out of range Replace the ICP board. See service manual chapter “Replacement of the
ICP board”, page 214.
ICP FPGA Temperature out of
range
Temperature on ICP is too high. Current active fans have errors. Solve the
fan problem first.
For a correct airflow, check if all covers are closed.
Ambient temperature is too high. Reduce the ambient temperature.
ICP FMT FPGA Temperature
out of range
Temperature on ICP is too high. Current active fans have errors. Solve the
fan problem first.
For a correct airflow, check if all covers are closed.
Ambient temperature is too high. Reduce the ambient temperature.
ICP Flash Update Error Replace the ICP board. See service manual chapter “Replacement of the
ICP board”, page 214.
ICP real time clock error 1. Clear the error by configuring the RTC (Real Time Clock) of the ICP.
See user manual Communicator chapter “Set up of the ICP clock”,
choose the option UTC/GMT time calculated from current PC time
current time.
• If the error stays:
• replace the RTC (Real Time Clock) battery of the ICP board. See
“Replacement of the RTC battery of the ICP board”, page 214.
• Clear the projector error 5800 “ti-icp - system status = fail” with error
message “ICP real time clock error” by configuring the RTC (Real
Time Clock) of the ICP. See user manual Communicator chapter
“Set up of the ICP clock”, choose the option UTC/GMT time
calculated from current PC time current time.
• Clear the projector error 5834 “physical marriage tamper event” by
remarrying the projector. See service manual chapter "Authorization
to clear security warning on the projector".
2. If problem remains, replace the ICP board. See “Replacement of the
ICP board”, page 214
Satellite Hardware Mismatch Replace the Light Processor assembly. See service manual chapter “Light
Processor replacement process”, page 97.
Other possible causes of this error code:
Troubleshooting
