R5906848 /04 DP2K SLP Series 375
Code 21353: “lpt 1 - lls bank 9 avg voltage too low”
Situation Solution
Wiring issue. Check / reseat the wiring between the Peltier Control Board and the small
interconnection boards of the Light Source. Replace the wiring if
necessary.
malfunction Peltier Control
Board
Replace the Peltier Control Board. See “Replacing the Peltier Controller”,
page 64.
Malfunction Light Source PCB Replace the light source. See service procedure “Laser Phosphor Light
Source”, page 59.
Code 21356: “lpt 1 - lls bank 9 avg voltage too high”
Situation Solution
malfunction Peltier Control
Board
Replace the Peltier Control Board. See “Replacing the Peltier Controller”,
page 64.
Code 21357: “lpt 1 - lls bank 9 current too low”
For this error the same troubleshooting table can be applied to as for code 20335: “LDM 1-2 – bank 1 current
too high”.
Code 21360: “lpt 1 - lls bank 9 current too high”
For this error the same troubleshooting table can be applied to as for code 20335: “LDM 1-2 – bank 1 current
too high”.
Code 21361: “LDM 1 – Not configured (not initialized)”
For this error the same troubleshooting table can be applied to as for code 20279: “LDM 1 – Not configured
(initialization failure)”.
Code 21362: “LDM 1 – Not configured (not initialized)”
For this error the same troubleshooting table can be applied to as for code 20279: “LDM 1 – Not configured
(initialization failure)”.
Code 21365: “LCM1 – Not configured (invalid module type)”
Situation Solution
Invalid module type detected. 1. Upgrade the software. See procedure “Software update via
Communicator (DC update companion)”, page 249.
2. Malfunction Controller board of the Light Source Fan Interconnection
Board. Replace Controller board. See service procedure “Replacing the
Light Source Fan Interconnection Board”, page 72.
Code 21366: “LCM1 – Not configured (no communication)”
Situation Solution
No connection with Fan
Interconnection Board
Check / reseat all the wiring of the Light Source Fan Interconnection Board
on top of the light source.
First install of Light Source Upgrade the software. See procedure “Software update via Communicator
(DC update companion)”, page 249.
Troubleshooting
