Baumuller b maXX BM1000 - Page 83

Error detection and troubleshooting
Manual b maXX
®
BM1000
Document No. 5.07003.04
83
of 174
8
0052
hex
ov Over voltage
The DC link voltage has
exceeded its maximum
allowable value.
PWM
inhibit
m Check if the input voltage falls within the
rated device input voltage range.
m Check for possible voltage transients.
m DC link over-voltage may also be caused
by motor regeneration. Either increase
the deceleration time or add an optional
braking resistor (and brake unit).
m Check whether the required braking pow-
er is within the specified limits.
0054
hex
GFF Ground fault PWM
inhibit
When (one of) the output terminal(s) is
grounded, short circuit current is more than
50
% of b maXX
®
rated current, the drive
power module may be damaged.
NOTE: The short circuit protection is provid-
ed for b maXX
®
drive protection, not for
protection of the user.
m Check whether the IGBT power module
is damaged.
m Check for possible poor insulation at the
output line.
0062
hex
PtC1 Motor overheat protec-
tion
P0119
m Check if the motor is overheated
m Check P0117 to P0122 settings
0063
hex
oL1 Overload 1
I²t > 100 %
PWM
inhibit
m Check for possible motor overload.
m Check electronic thermal overload set-
ting.
m Use a higher power motor.
m Reduce the current level so that the drive
output current does not exceed the value
set by the Motor rated current P0054.
0070
hex
PGEr Communication error
PG card (option card)
P1077
m Check or change PG option card
00A0
hex
cE10 Communication error
modbus
P0862
m Check the RS485 connection between
the b
maXX
®
drive and RS485 master
for loose wires and wiring to correct pins.
m Check if the communication protocol, ad-
dress, transmission speed, etc. are prop-
erly set.
m Use the correct checksum calculation.
Fault
code
Fault
name
Fault description Error
reaction
Corrective actions
