ADDRESS ON: loss of a loop device.
SAME ADDRESS ON: two devices on the same loop have the same address.
SILENCE
ON: the SILENCE button has been used to places the SILENCEABLE
Outputs in standby status. DAY mode SILENCE status will be held until
the SILENCE button is pressed again. NIGHT mode SILENCE will be
held for the programmed SILENCE time.
Z01 ÷ Z16
ON: the corresponding zone is in ALARM Status.
Flashing (3 secs. ON - 1 sec. OFF): the corresponding Zone is in PRE-
ALARM status .
Flashing (1 sec. ON - 0.5 sec. OFF): the FIXED delay is active.
Flashing (2 secs ON - 2 secs OFF): the PAS delay is active.
BUTTON FUNCTION
SILENCE
Places the SILENCEABLE Outputs in standby status: DAY mode
SILENCE status will be held until the SILENCE button is pressed again.
NIGHT mode SILENCE is held for the programmed SILENCE time.
ACK Activates the PAS delay (if pressed when the FIXED delay is active).
RESET REARMS the control panel.
TEST
Tests the control panel buzzer and LEDs. When this button is pressed,
all warning LEDs should light and the buzzer should emit a intermittent
acoustic signal (1 sec. beep - 1 sec. pause).
PART DESCRIPTION
1 Control panel door with Plexiglas window
2 Pocket for zone description
3 LCD 4 rows ---- 20 columns
4 Command panel
5 Control panel door lock
6 Two screws for securing command panel and battery compartment door
7 Battery compartment door stop
8 Battery compartment door
12 Analogue Fire Control Panel FireClass200
