Programming: Fire detectors
Figure 16 shows the fire detector parameters.
Description This is the non-editable description of the device type.
Analogue Value This shows the non-modifiable real-time values measured by the device.
Label This is for the editable device-label (up to 20 characters). The system will
use the label as the device identifier.
Associated Zone Each device can be associated with 4 of the 16 software zones. If a device
goes into ALARM status, all the zones it is connected to (associated
zones) will also go into ALARM status.
Alarm threshold This parameter determines the device threshold, if this limit is exceeded
the control panel will generate ALARM status. The threshold is indicated
by an arbitrary unit: 00 to 99 (default 50%).
Procedure type This determines the actions the control panel will perform when the device
threshold is exceeded:
* (default) - the control panel will signal the ALARM according to the preset
times and operating modes.
P (Prealarm) - the control panel will activate the ALARM delay.
A (Warning) - the control panel will activate a WARNING signal.
Alarm verify This option determines the number of times the device must exceed the
Alarm threshold before the programmed actions will be activated.
If the Alarm verify counter is set at 99, the control panel will not take into
account the number of times the device detects alarm conditions, but will
consider only the length of time the alarm conditions persist. In this way,
the control panel will not generate an alarm until the preset "Alarm verify"
time expires.
Timer The Timer option from the OPTIONS menu will allow you to program the
hours and days of the week when the Alarm threshold must be increased.
It is possible to set T Timer, type S Timer or no Timer (indicated by **).
+
If you set both timers, the highest values will be applied.
Loop This shows the loop the device is connected to.
Address This shows the device address.
44 Analogue Fire Control Panel FireClass200
