Select Causes / Events from the PRG:
TELECOM MODULE menu and assign
the events to the channels (1 through 8).
The Telecom module will send the code to
the programmed telephone numbers when
the assigned events occur.
When channels (1 through 8) are programmed ---- program the corre-
sponding parameters (see figure 27).
+
For details regarding the Double Knock, Zone Warning and Point Warning
options refer to the Output Modules section page 48.
Telephone Numbers (T.Num)
Select the T.Num. option from the PRG:
TELECOM MODULE menu, the display
will show the Telephone Numbers menu.
Use the ↑ and ↓ arrows to scroll the Number List. Select the identifier
Number (01 through 32), enter the corresponding telephone number then
press ↵ to confirm and continue. Use the ← and → arrows to scroll the
entered telephone number and delete any mistakes.
Options
Select Options from the PRG: TELECOM
MODULE menu. The display will show ...
Sel Select Pulse or DTMF, according to local requirements. The Telecom
module is programmed to dial in DTMF (factory default). However, if both
modes are available select DTMF as it is faster.
C.D.T. If the Check Dial Tone option is disabled OFF ---- the telecom module will
dial the programmed telephone numbers assigned channel in alarm status,
without checking for the dialling tone.
If the Check Dial Tone option is enabled ON ---- the telecom module will
will dial the programmed telephone numbers only when the dial-tone is
detected, otherwise, it will release the telephone line and restart the alarm
cycle from the same telephone number: after 4 attempts the Telecom mod-
ule will exit and step to the successive telephone number.
The control panel comes with the Check Dial Tone option enabled (ON).
PRG: TELECOM MODULE
Digital Communic.
Causes / Events
C:1,2,3,4,5,6,7,8
PRG: TELECOM MODULE
Telephone Numbers
Number : __
____________________
PRG: TELECOM MODULE
OPTION Tel.
Sel=_C.D.T.=___RT=_
AK=___J=___ C/R_/_
78 Analogue Fire Control Panel FireClass200
