INSTALLATION
ATTENTION Installation of the FireClass200 must be carried out in
strict accordance with the instructions herein and in compliance with
the local laws and bylaws in force.
Work carefully through the following steps (refer to the figures on pages 11
and 13).
Ø Plan the system layout.
Ø Lay the cables.
Ø Mount the control panel.
Ø Install add-on boards (if necessary).
Ø Complete the connections.
WARNING: DO NOT connect the Mains until all other wiring has been
completed.
Ø Program the control panel parameters.
Ø Test the system (detectors, signalling and ancillary devices).
Mounting the Control panel
When selecting the mounting location, ensure that:
Ø the Mains power, peripherals and the telephone line can be connected to
the control panel without difficulty;
Ø there is at least 20 cm space on all sides of the control panel to allow for
air flow.
Work carefully through the following steps.
1. Open the control panel door 1: pull the plastic bag 21 through the wire en-
try 22 (the control panel key is inside the plastic bag).
2. Remove the screws 6 and the control panel frontplate.
3. Lift the battery-housing door off its hinge 7 and open the door.
4. Drill the anchor screw holes 12 (use the backplate for the screw locations).
CAUTION Check for water pipes and cable conduits before drilling.
5. Pull the chased wires through the wire entry 22 and attach the control
panel to the wall.
INSTALLATION 21
