QUICK GUIDE
This quick guide holds all the information required by installers with some
knowledge of the FireClass200 fire control panel, or of fire control panels in
general.
General features
Below are some of the technical features of the terminals on the Main
board, Output Expanders and Repeaters.
FireClass200
FC200 FC200/S-FC100
Mains Voltage (1)
117 V 50-60 Hz ±10%
230 V 50-60 Hz ±10%
Maximum current 1.3 A @ 117 V
0.9 A @ 230 V
1.0 A @ 117 V
0.7 A @ 230 V
Maximum current available (2) 2 A 1 A
Low voltage range
19.0 ÷ 27.6 V
Low voltage ripple 1 %
Battery type:
make
model
two 12 V - 17 Ah
YUASA
NP 17-12 FR
or the equivalent with case flame class
UL94-V2 (or over)
Temperature range
-5 ÷ +40 °C
Dimensions (L*H*P) 432*577*131 mm
Max. weight (3) 21 Kg
(1) As per the local Mains power voltage.
(2) For the power supply to external devices.
(3) With two 12 V - 17 Ah batteries.
Repeater
Mains voltage 27.6 V
Maximum current 180 mA
Temperature range
-5 ÷ +40 °C
Dimensions (L*H*P) 195*178*45 mm
Weight 1.1 Kg
QUICK GUIDE 95
