Bentel Security FireClass 200 - Connections: Loop 1 and Loop 2

5b. If the control panel is programmed as
MASTER, the display will show ...
Select the required loop (1 or 2) to access and program the parameters of
the loop devices. Refer to the "Connections: Loop 1 and Loop 2" section.
Select 3 to access and program the parameters of the RS485 network de-
vices of the MASTER panel (refer to "Network Devices").
Connections: Loop 1 and Loop 2
+
The following instructions apply to loops 1 and 2.
+
The example shows loop 1 with two optical smoke detectors at addresses
1 and 2.
1. Select the Loop 1 option from the ANALY-
SIS CONNECTIONS menu (press 1) and
program the loop 1 device parameters.
2. The display will show the loop 1 devices.
Smoke This shows the number of smoke detectors.
Temperature This shows the number of heat detectors.
Mod.IN This shows the number of input modules (IN).
Mod.OUT This shows the number of output modules (OUT).
Balanced
Outputs
This shows the number of bell outputs:
without Output Expander = 4 bell outputs;
with 1 Output Expander = 10 bell outputs;
with 2 Output Expanders = 16 bell outputs.
+
Use the Devices option from the PROGRAMMING menu to program the
Bell Outputs.
Analysis connections
1)LOOP 1
2)LOOP 2
3)NET
Analysis connections
1)LOOP 1
2)LOOP 2
3)NET
Loop 1 devices:
Smoke :## Thermal:##
Mod.IN:## Mod.OUT:##
Balanced outputs :##
PROGRAMMING 41
