Connecting the Power Supply
The power systems of this control panel conform with EN54-4.
IMPORTANT Connect the Panel to a Mains power supply that com-
plies with the required specifications (see label). DO NOT powerup the
Panel with a voltage different to requirements.
Ø Connect the external power supply to terminal 26: connect Earth to terminal
[ ]; Neutral to terminal [N] and Line to terminal [L].
Ø Fit the two 12 V - 17 Ah batteries; connect in series to the jumper 20 (sup-
plied); connect the dry contacts to the connector 18.
Ø Insert the jumper 34.
IMPORTANT In compliance with safety regulations, the Line must be
connected to terminal [L] and the Earth to terminal [ ]. An automatic
isolating switch must be fitted to protect against overvoltage and short-
circuit.
+
The control panel will rearm automatically when power restores after black-
out.
+
Use YASA 12 V - 17 Ah batteries - model NP 17-12 FR, or similar, with
UL94-V2 (or over) case flame class.
+
Respect the connection polarity. In the event of inverted polarity, replace
the fuse 41 (F 6.3A 250V).
+
The display configuration on power-up depends on the operations done
prior to power failure.
Ø No parameters changes prior to power failure will be indicated by the green
NETWORK LED (ON) and the following messages (shown intermittently).
From this status you can access the system by pressing any key except
TEST.
FIRE CLASS 2ØØ
No Devices
Default Data
ØØ:ØØ 23/11/98 Mon
FIRE CLASS 2ØØ
Hit a Key
to take
control
32 Analogue Fire Control Panel FireClass200
