Network
When the Fire control system is fully installed, and several control panels
are connected via RS485: one of the control panels must be programmed
as MASTER and all the others as SLAVES.
Select the NET option from the SYSTEM menu to program the MASTER
and SLAVES. It is possible to connect the MASTER panel to one of the
SLAVE panels on the network. In which case, the LEDs and display of the
MASTER panel will show the status and parameters of the SLAVE panel.
The commands made on the MASTER panel will be effective also on the
SLAVE panel.
Select the NET option from the SYSTEM
menu (press 6).
Status Select the operating mode of the control
panel: MASTER or SLAVE # (the address
1 through 7 will be indicated in the space
filled by # in the example). The example
shows the control panel programmed as
SLAVE 1 (default).
+
The control panel will RESET automatically each time the control panel
status is changed.
Remote
connection
Specify the remote connection of the
MASTER to a SLAVE panel.
Press the ↵ key to confirm, or ESC to exit without saving and step back to
the SYSTEM menu.
+
If Remote Connection with a SLAVE panel has been programmed, on exit-
ing the NETWORK window, the MASTER panel display will be the same
as the slave.
Press the ACK key to end the remote connection. If no key is pressed
within 20 seconds the remote connection will end automatically. The MAS-
TER panel will RESET when the connection ends.
PRG: SYSTEM
1=Date/Time 2=Blink
3=Wire 4=SIL 5=WT
6=NET 7=Printer
PRG: SYSTEM
NET
Cond.: Slave 1
****** -> ******
PRG: SYSTEM
NET
Cond.: MASTER
MASTER -> Slave #
70 Analogue Fire Control Panel FireClass200
