USING THE SYSTEM
The FireClass200 system can be managed from the main panel, over-the-
phone (via a Telecom interface) and/or through the FC200/SW software
application (the computer must be connected locally via RS232 serial port).
The locked cabinet door allows access to authorized key holders only (Ac-
cess Level 2A).
There are three main phases with different access levels, as follows.
Programming The Programming phase allows the installer to program the control panel
and peripheral devices (detectors, modules, repeater and slave panels).
Access to this phase requires entry of the Installer PIN (Access Level 3A).
Modifying The Modifying phase allows users to disable the control panel peripherals
and delete (clear) the counters and memory. Access to this phase requires
entry of the Installer PIN or a User PIN (Access Level 2B).
Reading
Parameter
The Reading Parameter phase allows users to:
---- view and/or print the control panel log (events and programming data);
---- check the control panel and peripheral device parameters;
---- view the control panel version.
No PIN is required.
+
The instructions herein refer to system management from the Control
panel. For the instructions relative to programming and management
from a PC refer to the FC200/SW software instructions manual.
The parameter descriptions and values are valid in both cases.
Operating the system
Read this section carefully to get an overall view of the steps involved in
using the FireClass200 system.
Alphanumeric
keypad
Use the keypad to select the menu options, create labels and enter data
and codes.
Cursor keys
Use the ← and → keys to scroll the parameters, and the ↑ and ↓ keys to
select new values.
ESC] Use the ESC key to exit menus and windows and step back.
+
The ESC key usually exits windows without changing the data, however,
changes made in the device parameter windows will be saved.
USING THE SYSTEM 35
