Position the cursor on loop 1 then press the ↑ key to view the parameters
of the Conventional Line.
If a valid address is entered the display will show the respective data as
described in the "PROGRAMMING".
Press the ← or → key to view the parameters of the other Items of the
same type, or press ESC to enter another address (step 3.).
If an invalid address is entered at step 3.,
the display will show the Device not con-
figured message. Press ESC then retry.
Options
This option from the READING PARAMETER menu shows the parame-
ters of the Options.
Select Options from the READING PA-
RAMETER menu (press 2), or press ESC
to step back to the MAIN menu.
The display will show the OPTIONS menu
(refer to the OPTIONS section). Press
ESC to step back to the READING PA-
RAMETER menu.
Version
The Version option from the READING PARAMETER menu shows the
control panel version.
Select the Version option from the VIEW
PARAMETERS menu (press 3), or press
ESC to step back to the MAIN menu.
DEVICES LOOP1
Device not
configured
on LOOP 1
READINGS:
1=Dev./Zones/Outputs
2=Opt.3=Ver.4=Log.
5=Print 6=M.Telecom
RD: OPTIONS
Ø=P 1=W 2=V 3=D 4=T
5=S 6=H 7=D 8=Pulse
9=Extinction Mode
READINGS:
1=Dev./Zones/Outputs
2=Opt.3=Ver.4=Log.
5=Print 6=M.Telecom
88 Analogue Fire Control Panel FireClass200
