Repeater
PART DESCRIPTION
61
Wall mounting holes (3) for ( 5 mm)
62
Cable duct holes (2) for ( 30 mm)
63 Microprocessor
64 Address assignment switches
Figure 8 Repeater parts
20 Analogue Fire Control Panel FireClass200
