Connections: Network
+
The following example shows two repeater panels, connected to the Net-
work (addresses 1 and 8).
1. Select the Network option from the CON-
NECTIONS menu (press 3) and program
the network device parameters.
2. The display will show the devices found on
the RS485 Network.
3.
Press the ↵ key to view the parameters of
the device with the lowest address. If
several devices share the same address,
repeater panels will be shown first.
4. Position the cursor on the first character of
the second line then press the ← key.
5. The display will show the parameters of
the device at the previous address.
6.
Press the ↵ key to view the parameters of
the device at the next address.
7. Press ESC to step back to the CONNECTIONS menu (step 1.).
Analysis connections
1)LOOP 1
2)LOOP 2
3)NET
NET Devices:
Repeater :#
Slave units:#
Loop Expanders :Ø
PRG:Repeater
Repeater
Address :1
PRG:Repeater
Repeater
Address :1
PRG:Repeater
Repeater
Address :8
PRG:Repeater
Repeater
Address :1
PROGRAMMING 43
