3. The display will show the respective pa-
rameters (refer to "Programming: Re-
peater and Slave panels" section). If not,
the display will show the Device not con-
figured message. Press ESC to step
back.
To view the parameters of the other devices on the RS485 Network, follow
the procedure described in the "Auto-learning" section. Press ESC to step
back to the previous menu.
Password (PassWD)
The PassWD option from the PROGRAMMING menu will allow you to
change the Installer and user codes. Codes with 1 to 5 digits (0 through 9).
Select the PassWD option from the PRO-
GRAMMING menu (press 3).
The display will show ...
Select option 1 or 2 and refer to the respective section.
DEVICES NET
Device not
configured
on NET
1=Auto 2=Devices
3=PassWD 4=MesINI
5=Zones 6=Opt 7=Sys
8=Ver 9=Def Ø=Tel
CODES
Programming
1=Installer Code
2=User Code
54 Analogue Fire Control Panel FireClass200
