Bell Outputs
1. Select Bell Outputs option from the DE-
VICE menu to program the parameters of
the Main board bell outputs (terminals
[Cx]), and Output-expander bell outputs
(terminals [CX]).
2. Enter the address of the bell output con-
cerned. Table 1 shows the corresponding
Addresses of the bell output terminals on
the Main board and Output expanders.
The display will show the message in figure 22a. To access the parame-
ters shown in figure 22b ---- position the cursor on the third line of the dis-
play and then press key 1.
Most of the bell output parameters are described in detail in the "Output
Module" section. The following parameters are for bell outputs only.
+
Address 01 corresponds to the Type C Output. The Type C Output is non-
programmable, and will be activated each time the control panel goes into
ALARM status (it is possible to modify the label of the Type C Output).
ITemp When this option is selected the output will be activated in accordance with
the times set for option 1 from the OPTIONS menu.
If an invalid output or wrong address is en-
tered (accepted values are 01 through 16)
the display will show the Output not avail-
able message. Press ESC to go back to
step 2.
To view the parameters of the other bell outputs, follow the procedure de-
scribed in the "Auto-learning" section. Press ESC to go back to step 2.
Double knock As per the same option for Output Modules (page 48).
Zone Warning As per the same option for Output Modules (page 48).
Point Warning As per the same option for Output Modules (page 48).
PRG: Devices
1=LOOP 1 2=LOOP 2
3=Outputs BELL
4=NET
PRG: Output Bells
Enter Address
Output BELL : ##
Outputs BELL
Output
not
available
POSITION Main board Output expander no. 1 Output expander no. 2
TERMINALS C C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 C16
ADDRESSES 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
Table 1 Terminal number and address
52 Analogue Fire Control Panel FireClass200
