Digital Telephone Communicator (Digital Commun.)
To program the module as a Telephone
Communicator ---- select Digital Com-
mun. from the PRG: TELECOM MODULE
menu (press 2). The display will show the
Tel. Communicator menu.
The Telecom module provides 8 channels
for Telephone communicator use. Select
Codes (press 1) then select the required
channel.
.
Press ↵ to confirm and continue.
Program the selected channel, and all other channels including the Test
channel (T follows channel 8) as follows:
---- P enter the corresponding protocol number (as per below)
Protocols 1 = ADEMCO SLOW 10 BAUD
2 = ADEMCO FAST 14 BAUD
3 = FRANKLIN 20 BAUD
4 = RADIONICS 40 BAUD
5 = SCANTRONIC 10 BAUD
6 = CONTACT-ID (DTMF)
7 = SIA 300 BAUD
----User code enter the 4 digit user code (usually assigned by the central
station);
----Alm. enter the 2 digit Alarm code (usually assigned by the central sta-
tion);
----Res. enter the 2 digit Restore code (usually assigned by the central sta-
tion);
----Number enter 4 telephone numbers from the 32 available.
The telephone numbers must be defined in option 3 (refer to Tel.Num.
from PRG: Telecom Module menu).
PRG: TELECOM MODULE
Digital Communic.
1=Codes
2=Causes / Events
PRG: TELECOM MODULE
Digital Communic.
Codes
Channels =
PRG: T.Com.Ch.=__P=_
User Code =_____
Alm. =__ Res.=__
Number= __,__,__,__
