The Alm. and Res. codes are not required for protocol 7 SIA 300 BAUD.
The Res. code is not required for protocol 6 CONTACT-ID.
Press ↵, ESC or the arrow keys to confirm and exit.
Select Test to program the Test channel.
The display will show ....
Enter the Protocol number; the user code
and Test code (usually assigned by the
central station). Press ↵ to confirm. The
display will show ....
Enter the telephone numbers, the hour and day for the Test call.
The Test code is programmable for protocols 1 through 5 but is automatic
for protocol 6 CONTACT ID, and protocol 7 SIA 300 BAUD.
PRG: T.Com. Test P=_
User Code =____
TEST CODE__
->> Period
PRG: T.Com. Test
Number=__,__,__,__,
Hour __:__
Day = xxxxxxxx
PRG: T.Com. Ch.= 01
P=1SØØ P=1SØØ P=1SØØ
Z=ØØ Z=ØØ Z=ØØ Z=ØØ
G:xxx xxx xxxx
Fault:
*** = none;
Ft = Fault;
FtN = Net Fault
General condition
Alarm:
*** = none;
AI = Alarm;
2Al = Double Alarm
Prealarm:
**** = none;
Pre = Prealarm;
PreN = Net Warning;
Wrn = Warning;
WrnN = Net Warning;
PreZ=Prealarm Zone
WrnZ=Zone Warning;
WrnP=Point Warning
Description
Zones:
00 ÷ 16
Channels: 1 ÷ 8
To Next Page
