Options with requirements
The FireClass200 control panel provides the following options with require-
ments (complies with European norm EN54 part 2):
Ø outputs to fire alarm routing equipment
Ø co-incidence detection
Ø fault signals from points
Ø disablement of addressable points
Ø Test condition
Telecom Module FC200/COM (Accessory item)
The Telecom Module sends recorded messages to programmed telephone
numbers and, using reporting protocols, transmits data to central stations.
This module allows operators to manage the system over-the-phone by
means of the FC200/SW software package.
Description
r 8 independent channels
r Records one 11 second alarm message per channel
r 32 programmable telephone numbers
r Accepts 15 digit telephone numbers and 1 or 5 second pauses
r Repeats alarm messages for up to 20, 40, 60 or 80 seconds
r Repeats call cycle up to 5 times
r Voice answer detection
r Bypassable "dial tone" test
r Telephone-line Interface
r Protected against over-voltage
r DTMF and Pulse dialling
r Digital recording/Message playback
r Non-volatile memory
r Manages the following reporting protocols:
ADEMCO SLOW 10 BAUD, ADEMCO FAST 14 BAUD, FRANKLIN 20
BAUD, RADIONICS 40 BAUD, SCANTRONIC 10 BAUD, CONTACT ID
(DTMF), SIA 300 BAUD.
Alarm cycle
If an alarm channel triggers an alarm, the telephone dialler will generate
the respective alarm cycle (as per figure 1).
8 Analogue Fire Control Panel FireClass200
