Pulse
The Pulse option is for the ON and OFF Times of the Bell Outputs.
Select Pulse from the OPTION menu
(press 8).
Enter the required ON and OFF Times
The default value is 0 (accepted values: 0
through 25.5 seconds in steps of 0.5 sec-
onds).
+
The ON and OFF Times will be valid for the Bell Outputs programmed as
General Condition (refer to "Bell Output").
Extinction Mode
The Extinction Mode option will allow you to set up to 4 Extinction Modes.
The Extinction Mode parameters determine the operating mode of the out-
put devices and bell outputs, as follows.
Delay This parameter determines the output device delay. The default value is 30
seconds (accepted values:30 through 99 seconds in steps of 1 second).
Operating Mode This parameter determines how the Extinction Inhibition feature will work.
Ø ADD (default) - Extinction Inhibition will add 90 seconds to the pro-
grammed Delay;
Ø STOP - Extinction Inhibition will stop the Delay 10 seconds before it is due
to end. If Extinction Inhibition is undone, the Delay will restart and run for
10 seconds;
Ø FULL - Extinction Inhibition will refresh the Delay to its initial value. If Ex-
tinction Inhibition is undone, the Delay will restart.
+
If an activating condition occurs during Extinction Inhibition, Extinction de-
vices will be activated immediately.
LOG The LOG (logic) parameter establishes the conditions that will activate ex-
tinction.
Ø OR (default) - only one activating condition need occur.
Ø OFF - at least two activating conditions must occur simultaneously.
Time ON (TMP) This determines the time that Extinction devices will be active. Enter val-
ues from 0 through 20 minutes - 0 (zero) means that the Extinction devices
PRG: OPTION
Ø=P 1=W 2=V 3=D 4=T
5=S 6=H 7=D 8=Pulse
9=Extinction mode
PRG: OPTION
PULSES (IPul)
Time ON =ØØ,Ø sec
Time OFF =ØØ,Ø sec
64 Analogue Fire Control Panel FireClass200
