Via Gabbiano, 22 - Z.I. S.Scolastica - 64013 CORROPOLI (TE) - ITALY
Installation manual: Analogue Fire Control Panel FireClass200
Istruzioni Inst. Inglese Antin. FC200/UK ISTINSFC200/UK
The following versions of the Fireclass200 series are available:
FC200 - Master panel with 4 A Linear power supply;
FC200/S - Master panel with 2.5 A Switching power supply;
FC200/SL - Slave panel without power supply unit;
f a technical feature is common to all versions, the name Fireclass200 is used in the description.
Proper functioning of the FireClass200 components can be guaranteed ONLY when ambient
conditions, external to the cabinet, comply with the 3k5 category of IEC 721-3-3:1978.
The Loops of the FireClass200 control panel support 396 Analogue Devices.
The Conventional Zone of the FireClass200 control panel supports30 Conventional Devices.
The Fireclass200 supports a maximum of 512 devices in all.
In order to meet standards and qualify for IMQ Certification, the FC200/SL Slave panel must
be equipped with a BENTEL BA424 (27.6 V - 4 A) Linear power supply or
BENTEL BAQ60/24 (27.6 V - 2.5 A) Switching power supply.
Only the Manufacturer (Access Level no. 4 — refer to “Accss Levels” section) can install the
FC200/SL Slave panel power supply.
The FC200/SL Slave panel can operate ONLY when connected to a FireClass200 Master panel.
BENTEL SECURITY srl reserves the right to change the technical features of this product
without prior notice.
Fc100 - Master panel with 2.5 A Switching power supply;
I
FC200 - FC200/S - FC200/SL - FC100:
.
Hereby, Bentel Security,
declares the above mentioned Control Panels to be in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC
These Control Panels comply with
Installation of these systems must be carried out strictly in accordance with the instructions
described in this manual, and in compliance with the local laws and bylaws in force
The above mentioned Control panels have been designed and made to the highest
standards of quality and performance.
The manufacturer recommends that the installed system should be completely tested
at least once a month.
The complete R&TTE Declaration of Conformity for each Panel can be found
at www.bentelsecurity.com/dc.html.
.
.
BENTEL SECURITY Srl shall not assume the responsibility for damage arising from
improper application or use. The above mentioned Control panels have no user-friendly
components, therefore, should be serviced by authorized personnel only.
EN54-2EN54-4 1999;
