The Conventional Line supports 30 Conventional detectors.
WARNING Do not connect more than 512 devices to the control panel.
[EX] Reserved Output.
[485] Serial Bus ---- Terminals for FC200/REP repeater panels (maximum 8)
and FireClass200 Slave panels (maximum 7).
Serial bus terminals ---- 15[+] and 16[-];
27.6 V power voltage terminals ---- 14[ ] and 17[+].
[AUX] Aancilliary power 24 V ---- Power supply to devices that operate at 24 V
(protected by fuse 42 and powered by the standby batteries):
Ø Positive (27.6 V) on terminal 19[+];
Ø Ground on terminal [ ].
[CM1]
[NC1]
[NO1]
Non-supervised fault output ---- Dry contact relay for non-supervised de-
vices:
Ø During standby status ---- terminal 20[CM1] closes to terminal 21[NC1];
Ø In the event of fault ---- terminal 20[CM1] closes to terminal 22[NO1].
+
Blackout events (mains and battery supply failure) will activate the Non-su-
pervised fault output.
[CM2]
[NC2]
[NO2]
Non-supervised fire output ---- Dry contact relay for non-supervised de-
vices:
Ø During standby status ---- terminal 23[CM2] closes to terminal 24[NC2];
Ø In the event of fire ---- terminal 23[CM2] closes to terminal 25[NO2].
[C] Type C output - Supervised ---- Terminals for supervised devices acti-
vated by positive (24 V):
Ø During ALARM status ---- positive (27.6 V) on terminal [+]; ground on ter-
minal [-].
Ø This output can be bypassed via the DISABLE menu.
+
ALARM status will activate this non-programmable output.
[C2] [C3] [C4] Positive outputs - Programmable - Supervised ---- Terminals for super-
vised devices activated by positive (24 V):
Ø Output active ---- positive (27.6 V) on terminal [+]; ground on terminal [--].
Ø These outputs can be bypassed via the DISABLE menu.
Connect an EOL 2,700 ohm resistor (red-purple-red-gold) to terminals [+]
and [--] of these outputs. This will allow the control panel to detect and sig-
nal when the outputs are shorted and/or open.
NOTE: The EOL resistor must be connected to the last device on the Su-
pervised output.
Connect a diode (1N4002 or 1N4007) in series to the devices connected to
these outputs.
24 Analogue Fire Control Panel FireClass200
