P1 Patient Monitor User’s Manual
17-8
Menu item Function Description
12-Lead
Format
Set the format of
12-Lead waveforms on
a printout.
【12×1】：displays 12-lead waveforms on
one page in one column.
【6×2】：displays 12-lead waveforms on one
page in two columns, with 6 lines in each
column.
【6×2+1】：displays 12-lead waveforms on
one page in two columns, with 6 lines in
each column, and one rhythm lead waveform
at the bottom.
【3×4+1】：displays 12-lead waveforms on
one page in 4 columns, with 3 lines in each
column, and on rhythm lead waveform at the
bottom.
【3×4+3】：displays 12-lead waveforms on
one page in 4 columns, with 3 lines in each
column, and three rhythm lead waveforms at
the bottom.
Rhythm Lead1
Rhythm Lead2
Rhythm Lead3
Select the lead that will
be used as Rhythm
Lead 1, 2, or 3.
I、II、III、aVR、aVL、aVF、V1、V2、
V3、V4、V5、V6
Note: This setting is only relevant when 【6×2+1】, 【3×4+1】 or
【3×4+3】 is selected for 12-Lead Format.
