Bosch HTD 8 Series User Manual

1 692 104 611 2014-10-15| Robert Bosch GmbH
Technical data | HTD 8xx | 43 en
9. Technical data
9.1 Ambient conditions
9.1.1 Operation
Property Value/Range
Working temperature +5°C - +45°C
Humidity 20 % – 80 %
9.1.2 Storage and transportation
Property Value/Range
Temperature -25 °C – 45 °C
-13 °F – 113 °F
Humidity 30 % – 60 %
9.2 Dimensions and weight
Property Value/Range
Dimensions (W x D x H) 660 x 695 x 1780 mm
Weight 35 kg (66 lb)
9.3 Measuring range
Property Value/Range
Top and bottom alignment 0 – 600 mm / 10 m (0 - 6 %)
Right and left alignment: 0 – 1000 mm / 10 m (0 - 10 %)
Luminosity
0 - 240 lx (0 - 150.000 cd)
Illuminance
0– 150.000 lx
Height of optical centre point
from ground level
240 - 1450 mm
Power supply
(internalbattery)
12 V
Input voltage of battery
charger
100 – 240 V, 50/60 Hz
