Indication on the Graphic Display
Element Description
Switch for toggling between frequency response (magnitude) and phase response
(phase) display
Switch for adjusting the scale of the amplifier axis to 25 dB (± 12.5 dB) or to 50 dB (± 25
dB)
Switching the display of the corresponding speaker data for an amplifier channel on/off is
performed using the ”Show Speaker A” and ”Show Speaker B” switches.
Channel Parameters
Element
Default Range Description
Channel description and channel name
IRIS-Net REMOTE AMPLIFIER | en 212
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
