/IDX05 delay 0...350
/IDX06 polarity 0 / 1 0 = normal, 1 = inverted
/IDX07 compressor
bypass
0 / 1 0 = ON, 1 = BYPASS (obsolete with firmware V1.15)
/IDX08 compressor type
(ratio)
0...4 0 = 1/1, 1 = 1/1.4, 2 = 1/2, 3 = 1/4, 4 = 1/8 (obsolete with firmware V1.15)
/IDX09 compressor
threshold
-30...0 dB (obsolete with firmware V1.15)
/IDX0A compressor attack 0...99 ms (obsolete with firmware V1.15)
/IDX0B compressor
release
10...999 ms (obsolete with firmware V1.15)
/IDX0C limiter bypass 0 / 1 0 = ON, 1 = BYPASS
/IDX0D limiter threshold -30...0 dB
/IDX0E limiter release 10...999 ms
/IDX0F hipass xover type 0...17 0 = off, 1 = butter6, 2 = s12q05, 3 = s12q06, 4 = s12q07, 5 = s12q08, 6 =
s12q10, 7 = s12q12, 8 =
s12q15, 9 = s12q20, 10 = bessel12, 11 = butter12, 12 = linkwz12, 13 =
bessel18, 14 = butter18, 15 = bessel24, 16 = butter24, 17 = linkwz24
/IDX10 hipass xover
frequency
20...20000 Hz
/IDX11 lopass xover type 0...17 0 = off, 1 = butter6, 2 = s12q05, 3 = s12q06, 4 = s12q07, 5 = s12q08, 6 =
s12q10, 7 = s12q12, 8 =
s12q15, 9 = s12q20, 10 = bessel12, 11 = butter12, 12 = linkwz12, 13 =
bessel18, 14 = butter18, 15 = bessel24, 16 = butter24, 17 = linkwz24
/IDX12 lopass xover
frequency
20...20000 Hz
/IDX13 eq1 bypass 0 / 1 0 = ON, 1 = BYPASS
/IDX14 eq1 type 0...5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 = allpass
/IDX15 eq1 slope 0...2 0 = 0dB bypass, 1 = 6dB, 2 = 12dB
/IDX16 eq1 frequency 20...20000 Hz
/IDX17 eq1 gain -18...12 dB
/IDX18 eq1 quality 0.4...40
/IDX19 eq2 bypass 0 / 1 0 = ON, 1 = BYPASS
/IDX1A eq2 type 0...5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 = allpass
/IDX1B eq2 slope 0...2 0 = 0dB bypass, 1 = 6dB, 2 = 12dB
/IDX1C eq2 frequency 20...20000 Hz
/IDX1D eq2 gain -18...12 dB
IRIS-Net REMOTE AMPLIFIER | en 229
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
