../PRM/VALUE Reference value for comparison
TEMP Interpretation results in "true", when the measured amplifier
temperature is higher or equals the reference value.
../PRM/
CELSIUS
-20...150
[°C]
Temperature reference value
VU Interpretation results in "true", if any of the selected VU in any
of the selected channels is higher or equals the programmed
reference value.
../PRM/SEL NONE, IN,
OUT,
CMP, LIM
Any combination of the values listed is possible. LIM = Limiter
CMP = compressor
../PRM/CHAN A / B /
A,B
Selects channel A, or channel B, or channel A and B
../PRM/DB [dB] VU reference value
CTL_IN Interpretation results in "true", when the selected control
input is activated.
../PRM/IDX 1, 2 Selects a control input
ERRFLAG Interpretation results in "true", when one of the selected flags
is set. Any combination of the flags listed is possible.
../PRM/
DEVICE
Mask for device state/error flags
../PRM/IN_A Mask for input channel A state/error flags
../PRM/IN_B Mask for input channel B state/error flags
../PRM/OUT_A Mask for output channel A state/error flags
../PRM/OUT_B Mask for output channel B state/error flags
MEMFLA
G
Interpretation results in "true", when the actual state of the
selected memo flags resembles the reference pattern.
../PRM/MASK NONE,
1...16
Selects memo flags to be interpreted (listing)
../PRM/VALUE NONE,
1...16
Defines the expected reference pattern for memo flags
PRESET Interpretation results in "true", when the actual preset is
identical to a selected preset.
../PRM/DIRTY ON, OFF Selection is also valid, when parameters have been changed
(dirty)
../PRM/USER NONE,
1...6
List of selected user presets
