Store / Store to / Recall
Element Description
STORE STORE saves all momentary set DSP parameters into the actually loaded preset.
STORE TO... STORE TO...saves all momentary set DSP parameters into a selectable User Preset. A click
with the left mouse button opens the "Store Preset" dialog, where the preset can be selected.
If a new preset name is desired it shall be assigned in the NAME field before pressing the
STORE TO ... button.
RECALL...
RECALL loads and displays all DSP parameters that are stored in the selected preset.
CAUTION: The loaded preset becomes instantly audible when in on-line mode. Be sure to
select the desired preset with the correct set of parameters. In the worst case, this could
lead to severe damage to the connected loudspeaker cabinets due to improper signal
processing!
PROTECT... The user presets of the RCM-28 can be password protected, so they can only be overwritten
when the user knows the password. A click with the left mouse button opens the “Protect
User presets” dialog, where the password can be entered. Press the Set Password button to
activate the protection. Enter the password and press the Unlock User presets button to
deactivate the password protection.
IRIS-Net
REMOTE AMPLIFIER | en 261
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
