Preset after Startup
Element Description
The indicated preset is loaded after power on or reset of the power amplifier. If no preset number is
indicated the last used setting is loaded after power on or reset.
Clicking the ASSIGN .. button opens the Set Initial Preset... dialog. In this dialog a factory preset or
user preset can be selected as startup pre- set.
Clicking the X buttons clears the Startup preset selection.
Import / Export of Preset Files
IRIS-Net allows the storing of all DSP parameters of an amplifier together with the according preset name in a file, and
to load amplifier parameters from these files. Therefore, IRIS-Net creates a sub-directory \RCM-28 Presets during
installation, where all factory-presets are saved in to. It is recommended to save your own presets in this directory as
well. For improved organization, creating more sub-directories within the directory \RCM-28 Presets is permissible.
Element
Description
After clicking onto IMPORT PRESET an „Open File“ dialog box appears. Enter the correct path of the
directory in which the desired file is located and select the desired preset file to be opened. This loads
and afterwards displays all DSP parameters that are stored within that file.
CAUTION: The loaded preset becomes instantly audible when in on-line mode. Be sure to select the
desired preset with the correct set of parameters. In the worst case, this could lead to severe
damage to the connected loudspeaker cabinets due to improper signal processing!
After clicking onto EXPORT PRESET a „Save File“ dialog box appears. Enter the correct path of the
directory that you want to save the data in. Enter a file name (without extension). Click onto the SAVE
button to store all DSP parameters together with the corresponding file name. „.ds“ is automatically
added as file extension.
INPUT PARAMETRIC EQ
Both input channels of the RCM-28 employ 10-band parametric equalizers each, which allow programming highly
variable speaker equalization to match a PA-system to different environmental and acoustical requirements.
IRIS-Net
REMOTE AMPLIFIER | en 262
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
