Channel Parameters
Element
Default Range Description
Channel name.
A click with the right mouse button opens the ”Copy & Paste” menu, which
allows convenient copying all delay parameters of the corresponding output
to any other delay within the same project.
0 ms 0 to
1000 ms
Delay allows delaying the corresponding output channel’s audio signal by an
adjustable period of time.
Press the ACTIVE button to deactivate the output delay.
General Parameters
Element
Default Range Description
ms ms, samples,
ft, in, m, cm,
µs, s
This lets you select the unit of measurement for the delays.
20 °
Celsius
-20 to 60 °C
-4 to 140 °F
Entering the actual ambient temperature is possible here. In case you have
chosen a distance value as unit of measurement for the delay, delay times are
corrected in relation to temperature. Temperatures can be entered as °C or
°F.
Editing Delays by ”Dragging the Mouse” in the Graphics Display
The graphics display shows the corresponding speaker symbol in color as soon as a delay has been activated. Clicking
with the left mouse button onto the speaker icon and keeping the mouse button pressed allows dragging the symbol to
the right or the left, which results in a change of the selected channel’s delay time. A delay’s title is shown black as
soon as the mouse cursor is positioned on top of the corresponding icon to provide improved overview and handling.
IRIS-Net
REMOTE AMPLIFIER | en 277
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
