Amplifier Info
Element
Description
AMPLIFIER MODEL Shows the amplifier type
AMPLIFIER FIRMWARE Shows the amp software’s version number (operating system, firmware)
RCM-810 FIRMWARE Shows the remote control module software’s version number (operating system,
firmware)
UPTIME Shows the uptime of the amplifier (standby not included).
Amplifier Setup
Element
Default Range Description
POWER DELAY Address *
150 ms
50...4000 ms
50 ms Steps
Allows programming an amplifier’s power-on delay. Setting different
delay times is recommended to prevent the mains fuse from blowing
when powering on several amps at the same time.
The value defaults to address * 150 ms
This dialog indicates the actual states of the two freely programmable
control inputs IN1 and IN2. A green indicator signals "not active", i.e.
the control input is open or "high". A red indicator signals "active", in
that case the control input is connected to the ground or "low".
This dialog is for manually controlling the two Open Collector control
outputs OUT1 and OUT2. Not engaged (blue) indicates that the
control output is deactivated or highly resistive while engaged (red)
indicates that the control output is activated and connected to the
ground (closed).
HINT: When a control output has already been programmed, the
programmed function defines the state of the control output and
manual control is not possible.
IRIS-Net
REMOTE AMPLIFIER | en 293
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
