Bosch IRIS-Net User Manual

Element Default Range Description
0 1...65536 Here, you can specify which job code numbers an amplifier transmits on
the occurrence of specific events. Entering random numbers between 0
and 65536 is possible.
(empty) This column allows specifying an event (condition) that triggers the
corresponding transmit job code. Clicking the desired line in the Condition
menu opens a dialog field that shows all accessible functions. The table
"Output and Transmit Job Conditions" lists all functions together with
their individual settings.
(empty) Here you can set the different function parameters. For more information,
please refer to the table "Output and Transmit Job Conditions".
(empty) Certain functions allow specifying optional parameter values.
0 ms 0...10027 ms
16.33 ms
Steps
Here, you can program delay or debouncing times. A transmit job code is
sent following a specific event and after the specified time interval has
past.
This column allows entering whether a job code is transmitted when the
specified Condition is "tru" (no entry) or "false" (click "X" to signal an
inverted state).
Input and Receive Job Function: The following table lists all functions together with their individual settings, which
can be triggered via control input or Receive Job.
Function
Parameter Opt. Value Function executed
Empty - - None
Power off on flip Power Off (Standby) Power On
Power-status change (ON to Stand-by and reverse)
Absolute Mute 0 = not
muted, 1 =
muted
Set the specified absolute parameter value for the selected parameter
Toggle Mute Changes the status of the selected parameter
Memoflag Set, Clear,
Toggle
Memoflags 1 -
16
Sets, erases or changes selected memory flags. Up to 16 memory flags
are available and simultaneously accessible.
Output and Transmit Job Conditions: The following table lists all amplifier statuses that can be used for triggering
control outputs or for sending Transmit Job Codes.
Function
Parameter Opt.Value Invert Triggering Event / Status
Change
Empty - - Not configured
IRIS-Net REMOTE AMPLIFIER | en 297
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
