Adds a new preset to the preset list that holds the DSP
configuration’s current settings. Up to 60 presets can be used.
Number of the preset. Up to 60 presets can be used.
Name of the preset.
A preset includes all dsp settings.
Audio outputs are muted during recall of the preset when the
option MUTE AUDIO DURING RECALL is activated.
Stores the preset that you have selected and all current
parameters in the preset list.
Loads the selected preset into the preset list.
Deletes the selected preset from the list.
Shows a description of the selected preset.
The preset that you have selected in the preset list is automatically
loaded upon power-on or restart of the N8000. With no startup-
preset assigned, the N8000 starts using the settings that were
active before it had been switched off.
HINT: If no start-up preset is assigned, under certain
circumstances not all parameter changes can be restored after a
restart of the N8000. In this case the audio output is muted after
restart. Assigning a startup-preset is strongly recommended.
Cancels the assignment of the previous start-preset.
SCENES
An existing preset can be converted into a scene. A scene contains a defined subset of the preset parameters. Select
the preset to be converted from the Preset List and press the SCENE button. The following dialog box appears:
IRIS-Net DIGITAL MATRIX | en 320
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
