INPUT SUPERVISION
(PLT)
Pilot tone recognition fault at the inputs of the P 64. Each input can separately be configured
in the input blocks.
COLLECTED ERROR
STATE
The FAULT-LED on the front panel of the P 64 lights at the occurrence of this type of error.
Manually setting or resetting an error.
Clears the indication of errors for which HOLD had been activated. Indication of still existing
errors is not reset.
CAN INTERFACE FAULTS
Error
Description
CAN FAILURE CAN self-testing was not successful. The CAN-Bus does not function.
CAN BUS OFF The CAN-Bus is in the "Bus OFF" state.
CAN BUS PASSIVE The CAN-Bus is in "Passive" mode.
REMOTE AMPLIFIER CONFIG The RCM configuration does not represent the RCMs that are actually connected.
REMOTE AMPLIFIER FAULT Collected Error for at least one RCM has been set.
FAN SPEED
Speed
Description
0 Off
1 Slow
IRIS-Net DIGITAL MATRIX | en 356
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
