-35.0 dBu -60...0 dBu This field allows setting the level of the pilot tone signal.
HINT: Level (dBu) can only be configured OFFLINE.
19000 Hz 20...20000
Hz
This field allows setting the frequency of the pilot tone
signal. The set frequency applies to all outputs, for which
the pilot tone signal has been activated.
HINT: Freq (Hz) can only be configured OFFLINE.
AUTO MIXER
IRIS-Net provides Auto mixers with 2, 4, 6, 8, 10, 12, 16 or 24 inputs. For the 16 or 24 input Auto mixers
a DSP-2 DSP extension card is required.
Element Default Range Description
Activates auto mixing function of corresponding input.
The "CLIP" LED lights when the signal level nears clipping
(+21dBu).
If a signal is present at the input, the "SIG" LED lights.
0.0 dB -80...0 dB (Post-)Fader for setting the levels in corresponding inputs. This
fader works "post auto mixer algorithm", this means the level is
changed after the automated evaluation of level distribution.
IRIS-Net DIGITAL MATRIX | en 377
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
