100 ms 10...1000 ms RELEASE defines how fast the output signal returns to
the nominal level once the threshold level is exceeded.
BYPASS activates (not engaged) or deactivates
(engaged) the expander.
0 dB -30...0 dB Fader for setting the output level.
The fader display shows the numerical value of the
current fader setting and additionally provides the
possibility for entering a desired value.
FIR FILTER
IRIS-Net provides FIR Filter blocks (Finite Impulse Response) of order 256 up to order 1792.
Channel Parameters
Element
Description
Switch for displaying frequency response (magnitude) or phase response
(phase)
Switch for scaling the amplitude axis to 25 dB (± 12.5 dB) or to 50 dB (± 25 dB)
Description of the FIR filter currently in use.
IRIS-Net DIGITAL MATRIX | en 399
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
