PEAK/TEMP-Limiter-Parameter
Element Default Range Description
AMPLIFIER Default
(39 dB)
User, Default (39 dB), S900, S1200,
CL800, CL1200, CL1600, CL2000,
LX1600, LX2200, LX3000, L1000
(0dBu), L1000 (+6dBu), L1000
(26dB), L1600 (0dBu), L1600
(+6dBu), L1600 (26dB), L2400
(0dBu), L2400 (+6dBu), L2400
(26dB),
H 2500 (0dBu), H 2500 (32dB), H
2500 (35dB), H 5000 (0dBu), H
5000 (32dB), H 5000 (35dB),
SL900, SL1200, SL1800, SL2400,
DSA8204, DSA8206, DSA8209,
DSA8212, Q44, Q66, CP1200,
CP1800, CP2200, CP3000S,
CP4000S, P1200 (0dBu), P1200
(+6dBu), P1200 (26dB), P2000
(0dBu), P2000 (+6dBu), P2000
(26dB), P3000 (0dBu), P3000
(+6dBu), P3000 (26dB), TG5
(0dBu), TG5 (32dB), TG5 (35dB),
TG7 (0dBu), TG7 (32dB), TG7
(35dB), Q44 MKII, Q66 MKII, Q99,
Q1212, CPS2.4, CPS2.6, CPS2.9,
CPS2.12
If the amplifier type used is not
available in this dropdown, select the
entry „User“. Then, select the field and
enter the gain of the amplifier. Please
refer to the technical documentation of
the amplifier or ask your dealer for the
correct gain setting.
THRESHOL
D AMP
OUTPUT
12 Vpk THRESHOLD AMP OUTPUT determines
the audio signal level above which the
peak limiter starts operating. Please
refer to the technical documentation of
the used speaker for the power limit
(program power or music power).
then, use the Limiter Threshold
Calculator (Tools > Limiter Threshold
Calculator) to calculate the
corresponding voltage at the amplifier
output.
The Speaker Settings for DYNACORD
or Electro-Voice speakers already
include the correct setting for this
parameter.
IRIS-Net DIGITAL MATRIX | en 414
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
