PILOTDETECT
.FREQ
/
IDX1...IDX
8, ALL
R / W 20...2
0000
Frequency of pilot tone to detect
/
PILOTDETECT
.FLAG
/VALUE R 0x00...
0xFF
Status of pilot tone detection of
all inputs (1 = pilot tone detected,
0 = pilot tone not detected). The
last of the four hexadecimal
values corresponds in binary
representation to the 8 inputs.
/
PILOTDETECT
.ENABLE
/VALUE R 0x00...
0xFF
Activation of pilot tone detection
of all inputs. The last of the four
hexadecimal values corresponds
in binary representation to the 8
inputs.
Commands for MI-1 Module
Read
Write Values Description
/
PARA
M
/DS
P
/
ANALOGMI
CIN_x
/GAIN /
IDX1...IDX
8, ALL
R / W -80...18 Gain of input
/MUTE /
IDX1...IDX
8, ALL
R / W 0, 1 0 = not muted, 1 = muted
/POLARITY /
IDX1...IDX
8, ALL
R / W 0, 1 0 = normal, 1 = inverted
/
CHANNELIN
FO
/VALUE R / W Linking of inputs (Linked-
Button). Binary representation
of number is equivalent to
pressed Linked-Buttons.
/NAME /
IDX1...IDX
8, ALL
R / W max. 16
character
s
Input name
/RAMPTIME /
IDX1...IDX
8, ALL
R / W 0.001...
20
Ramping Time of input
(seconds)
/MIC.LINE /
IDX1...IDX
8, ALL
R / W 0, 1 Selects input level (0 = Mic level,
1 = Line level)
