MIC.PHANP
OWER
/
IDX1...IDX
8, ALL
R / W 0, 1 Phantom Power (+48 V) of input
(0 = off, 1 = on)
/MIC.GAIN /
IDX1...IDX
8, ALL
R / W 0...10 Microphone gain in steps of
6dB.
Commands for AO-1 Module
Read
Write Values Description
/
PARA
M
/DS
P
/
ANALOG
OUT_x
/GAIN /
IDX1...IDX
8, ALL
R / W -80...18 Gain of outputs
/MUTE /
IDX1...IDX
8, ALL
R / W 0, 1 0 = not muted, 1 = muted
/
POLARI
TY
/
IDX1...IDX
8, ALL
R / W 0, 1 0 = normal, 1 = inverted
/NAME /
IDX1...IDX
8, ALL
R / W max. 16
characters
Output name
/
RAMPTI
ME
/
IDX1...IDX
8, ALL
R / W 0.001...20 Ramping Time of output
(seconds)
Commands for Automatic Gain Control (AGC)
Read Write
Values Description
/
PARA
M
/DSP /
AGC_
x
/BYPASS /VALUE R / W 0, 1 0 = Bypass not activated, 1 =
Bypass activated
/
DECREASE
_TIME
/VALUE R / W 300...20000 GAIN DECREASE time in ms
/GAIN /VALUE R / W -6...18 Target Level in dB
/
GAINREDU
CTION
/VALUE R -30...30 Current Gain change as full scale
value (32 bit)
Transform given value into dB
by: 20 log (0x7FFFFF/ value)
/HOLD /VALUE R / W 50...60000 Hold time in ms
