TEMPERA
TURE
/VALUE R / W -20...60 Temperature in degree Celsius
/VALUE /VALUE R / W einheitenabh
äng ig
Delay time including unit. The
maximum delay time depends on
the used DSP block. Available
units are ms (millisecond), smp
(samples), ft (Foot), inch, m
(meter), cm (centimeter), us
(microsecond) and s (seconds).
Example: 588.235 ms
Commands for DI-1 Module
Read
Write
Values
Description
/
PARA
M
/DSP /
DIGITAL
IN_x
/CHANNELINFO /VALUE R / W 0...127 Linking of inputs (Linked-
Button). Binary representation
of number is equivalent to
pressed Linked-But- tons.
/
CHANNELMOD
E
/
IDX1...IDX
4
R 0...FF Channel mode of input signal 0 =
Not indicated,
1 = 2 channel,
2 = 1 channel,
3 = primary/secondary,
4 = stereo,
5 / 6 = reserved for user
applications,
7 = SCDSR,
8 = SCDSR (stereo left), 9 =
SCDSR (stereo right), FF
=Multichannel
/
CHANNELSTAT
USBYTES
/
IDX1...IDX
40
R First five bytes of Channel
Status Block.
/
CLOCKACCURA
CY
/
IDX1...IDX
4
R 0...3 Clock accuracy of input signal
(Consumer mode only)
0 = Level 2 (+/- 1000 ppm)
1 = Level 3 (variable pitch)
2 = Level 1(+/- 50 ppm, high
accuracy)
3 = reserved
/COPYRIGHT /
IDX1...IDX
4
R 0, 1 Copyright bit of input signal
IRIS-Net DIGITAL MATRIX | en 466
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
