HIGHFR
EQ
/VALUE R / W 1000...20
000
Frequency of HF FILTER
/GAIN /IDX1...IDXn R / W -12...12 Gain of filter. Index 1
corresponds to the LF FIL- TER,
index n corresponds to the HF
FILTER.
/
QUALIT
Y
/IDX1 R / W 0.4...40 Quality of LF FILTER
/IDX2 R / W 3...10 Quality of filter 1 to n
/IDX3 R / W 0.4...40 Quality of HF FILTER
/SLOPE /IDX1 R / W 1 = 6dB/
Oct,
2=
12dB/Oct
Slope of LF FILTER
/IDX2 R / W 1 = 6dB/
Oct,
2=
12dB/Oct
Slope of HF FILTER
/TYPE /IDX1 R / W 0 = PEQ,
1 =
Loshelv,
2 =
Hishelv,
3 =
Hipass,
4 =
Lopass
Type des LF FILTER
/IDX2 R / W for future use
/IDX3 R / W 0 = PEQ,
1 =
Loshelv,
2 =
Hishelv,
3 =
Hipass,
4 =
Lopass
Type of HF FILTER
