/GPOSTATE R / W 0, 1 per
GPO
State of the two GPOs.
The value 0 means „not activated“ (high
impedance). The value 1 means the
output is „activated“, so the out- put is
connected (low impedance) to signal
earth.
/MASTERERROR R 0, 1 Current COLLECTED ERROR STATE of
the RCM-810 (0
= not active, 1 = active)
/IN1...8 /NAME R max. 30
characters
Description (name) of input channel
/
OUT1...
8
/NAME R max. 30
characters
Description (name) of output channel
/STATEFLAGS R 0x00...0xF
F,
0x00...0xF
F,
0x00...0xF
F
24 Bit state flags of the output channel in
hexadecimal format.
: SMPS reports overload
: amp reports excessive Hf level
: low impedance load or short-circuit
detect 4 : thermal protection active
5 : in general: protect-mode active 6 :
protection mute active
7 : amp output relay off 8 : unused
9 : protection gain reduction active 10
and 11: unused
12 : load value result valid 13 :
speakerload shorted 14 : speakerload
opened 15 : pilot not detected
: unused
: thermal headroom below minimum
/COLLECT 0x00...0xF
F,
0x00...0xF
F,
0x00...0xF
F
Bit mask for state flag selection in
hexadecimal format.
/MUTE R / W 0, 1 0 = not muted, 1 = muted
Link-Numbers for linking adjacent ways of a crossover
Number of crossover ways
5 4 3 2 1
Link-Number 8 2
16 4
Hexadecimal representation of remote amplifiers connected to the device
IRIS-Net
DIGITAL MATRIX | en 488
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
